Package /
Category Switches / Pushbutton Switches
Description SWITCH PUSHBUTTON SPDT 6A 125V
PDF
/
Inventory: 4406
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Silver
Mount Panel
Mounting Type Panel Mount, Rear

Technical

Operating Temperature -30°C~70°C
Packaging Bulk
Published 2006
Series WB
JESD-609 Code e3
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard
Terminal Finish Tin (Sn)
Voltage - Rated DC 30V
Current Rating (Amps) 6A AC/DC
Orientation Vertical
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 6A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Plunger for Cap
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 12.50mm Dia
Electrical Life 15,000 Cycles
Mechanical Life 30,000 Cycles

Dimensions

Length 28.8mm
Width 19.4mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings Dust Tight, IP67, Waterproof
