UB216SKW036CF-2B
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches LOW PROFILE PSHBTTN ILLMNTD/PC AND SLDR
PDF
/
Inventory: 5276
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Package / Case 125
Housing Material Polyamide
Technical
Operating Temperature -25°C~50°C
Packaging Bulk
Published 2011
Series UB2
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Standard, Illuminated
Terminal Finish GOLD
Voltage - Rated DC 30V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Square, Button
Circuit SPDT
Switch Function On-On
Color - Actuator/Cap White
Illumination Voltage (Nominal) 2.1 3.5VDC
Illumination Type, Color LED, Red/Green
Electrical Life 10,000 Cycles
Mechanical Life 200,000 Cycles
Illumination Type LED
Illumination Color Green, Red
Life (Cycles) 10000 cycles
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
