UB16SKG035D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPDT 0.4VA 28V
PDF
/
Buying Options
Total Price: USD $9.51
Unit Price: USD $9.5128
≥1 USD $9.5128
≥10 USD $8.57296
≥100 USD $8.21392
≥500 USD $7.809824
≥1000 USD $7.495664
≥3000 USD $7.046864
Inventory: 40
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide
Technical
Operating Temperature -25°C~50°C
Packaging Bulk
Published 2009
Series UB
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Standard, Illuminated
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 28V
Actuator Type Plunger for Cap
Circuit SPDT
Switch Function On-On
Illumination Voltage (Nominal) 2VDC
Illumination Type, Color LED, Amber
Electrical Life 200,000 Cycles
Mechanical Life 200,000 Cycles
Illumination Type LED
Illumination Color Orange
Life (Cycles) 200000 cycles
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
