NP0115HG03NN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPST-NO 0.4VA 28V
PDF
/
Buying Options
Total Price: USD $3.37
Unit Price: USD $3.3704
≥1 USD $3.3704
≥10 USD $3.01928
≥100 USD $2.864928
Inventory: 89
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Resin
Actuator Material Rubber, Silicone
Technical
Operating Temperature -25°C~70°C
Packaging Bulk
Published 2012
Series NP01
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Standard
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Current Rating 14.2mA
Termination Style PC Pin
Voltage - Rated AC 28V
Actuator Type Square, Button (Not Included)
Circuit SPST-NO
Switch Function Off-Mom
Max Voltage Rating (AC) 28V
Max Current Rating 100mA
Electrical Life 500,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 28V
Mechanical Life 500,000 Cycles
Illumination Type Illuminated
Compliance
RoHS Status ROHS3 Compliant
