M2B25AA5G30-HA

NKK Switches
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description Pushbutton Switches MINIATURE PSHBTTN/PC
PDF
/
Buying Options
Total Price: USD $9.79
Unit Price: USD $9.7944
≥1 USD $9.7944
≥10 USD $8.82728
≥100 USD $7.718304
≥500 USD $6.470464
Inventory: 53
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Body Height 31.5468mm
Length 12.7mm

Technical

Solderability WAVE
Contact Function ON-(ON)
PCB Hole Count 10
Mechanical Life 200,000 Cycles
Max Voltage Rating (DC) 28V
Electrical Life 100,000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Max Current Rating 100mA
Max Voltage Rating (AC) 28V
Sealing EPOXY
Color - Actuator/Cap Black
Insulation Resistance 1000000000Ohm
Contact Resistance 0.03mOhm
Switch Function On-Mom
Circuit DPDT
Actuator Type Round, Button
Body Breadth 11.5062 mm
Voltage - Rated AC 28V
Termination Style PC Pin
Current Rating 1A
Reach Compliance Code not_compliant
Depth 31.35mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 28V
Power Rating 400mW
Type Standard
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Process Sealed
JESD-609 Code e4
Series M2
Published 2011
Packaging Bulk
Operating Temperature -30°C~85°C

Physical

Actuator Material Brass
Housing Material Polyamide
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 14 Weeks
