LB26SGW01-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches DPDT ON-ON SQUARE GRAY BODY RED CAP
PDF
/
Inventory: 3925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Housing Material Polyamide
Terminal Material PHOSPHOR BRONZE
Technical
Operating Temperature -25°C~70°C
Packaging Bulk
Published 2011
Series LB
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard
Additional Feature Non Illuminated Cap
Voltage - Rated DC 30V
Current Rating (Amps) 3A AC/DC
Current Rating 3A
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Body Length or Diameter 17.8054mm
Body Breadth 15.7988 mm
Actuator Type Square, Button
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Square - 16.20mm2
Contact Resistance 0.05mOhm
Insulation Resistance 200000000Ohm
Color - Actuator/Cap Red
Sealing EPOXY
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 100,000 Cycles
Mechanical Life 200,000 Cycles
Contact Current(AC)-Max 3A
Contact (AC) Max Rating R Load 3A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Travel 2.9972 mm
Dimensions
Body Height 21.4884mm
Length - Termination 0.295 inch
Actuator Length 0.197 inch
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
