EB2011-C-J34AFE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches MINIATURE PUSHBUTTON BUSHING MOUNT
PDF
/
Inventory: 4917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.157 inch
Body Height 3.4036mm
Technical
Life (Cycles) 100000 cycles
Contact Function ON-(ON)
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Illumination Color Green, Yellow
Illumination Type LED
Mechanical Life 100,000 Cycles
Electrical Life 25,000 Cycles
Illumination Type, Color LED, Green/Yellow
Illumination Voltage (Nominal) 2.2 2.1VDC
Color - Actuator/Cap Red
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Rectangular - 18.40mm x 15.00mm
Switch Function On-Mom
Circuit SPDT
Actuator Type Square, Button
Body Breadth 7.0104 mm
Body Length or Diameter 10.9982mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 3A
Current Rating (Amps) 3A AC
Type Standard, Illuminated
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
Series EB
Published 2012
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
Terminal Material COPPER
Center Contact Material COPPER
Actuator Material BRASS
Surface Mount NO
Mounting Type Panel Mount, Snap-In
Contact Plating Silver
Supply Chain
Factory Lead Time 8 Weeks
