AB11BH-FA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches Washable, Process Sealed Subminiature
PDF
/
Inventory: 6298
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polyamide
Actuator Material POLYCARBONATE
Center Contact Material PHOSPHOR BRONZE
End Contact Material BRASS
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2010
Series AB
JESD-609 Code e4
Feature Sealed - Fully
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Standard
Additional Feature MOUNTING BRACKET
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 28V
Body Length or Diameter 9.8044mm
Body Breadth 6.1722 mm
Actuator Type Round, Button
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 0.05mOhm
Insulation Resistance 500000000Ohm
Color - Actuator/Cap Black
Sealing EPOXY
Dielectric Withstanding Voltage 500VAC V
Electrical Life 50,000 Cycles
Throw Configuration SPST
Mechanical Life 50,000 Cycles
PCB Hole Count 4
Contact Function OFF-(ON)
Actuator Travel 1.0922 mm
Solderability WAVE
Bushing Length 0.177 inch
Washability SOLVENT
Dimensions
Body Height 19.7104mm
Length - Termination 0.122 inch
Actuator Length 0.248 inch
Compliance
RoHS Status ROHS3 Compliant
