XN4E-BL411MR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
30MM EMERGENCY-STOP
PDF
/
Buying Options
Total Price: USD $88.89
Unit Price: USD $88.889465
≥1 USD $88.889465
≥10 USD $83.857983
≥100 USD $79.111307
≥500 USD $74.633303
≥1000 USD $70.408787
Inventory: 1218
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP65
RoHS Status ROHS3 Compliant
Dimensions
Length 44mm
Height 104.4mm
Technical
Actuator Diameter 44 mm
Operating Force 32 N
Contact Current Rating 5A
Mechanical Life 250,000 Cycles
Max Voltage Rating (DC) 250V
Throw Configuration SPST
Electrical Life 100,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Red
Contact Resistance 50mOhm
Panel Cutout Dimensions Circular - 30.50mm Dia
Switch Function On-Off, Off-On
Circuit DPST-NO/NC
Actuator Type Round, Button, Mushroom
Approval Agency CCC, CE, CSA, EN, IEC, TUV, UL
Voltage - Rated AC 125V
Termination Style Screw Terminal
Current Rating 2A
Depth 44mm
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation Straight
Current Rating (Amps) 5A AC 2A DC
Voltage - Rated DC 30V
Voltage - Rated 250V
Type Emergency Stop
Termination Screw
Number of Terminations 4
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Padlock Style
Series XN
Published 2007
Packaging Bulk
Operating Temperature -25°C~60°C
Physical
Weight 20g
Mounting Type Panel Mount, Front
Mount Panel
Contact Plating Gold
Contact Material Gold, Silver
Supply Chain
Factory Lead Time 4 Weeks
