AML22JBC3AD
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches SQ 1 LED RED 5V DPDT PB SWITCH
PDF
/
Inventory: 7499
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Illumination Color Red
Illumination Type LED
Mechanical Life 25,000 Cycles
Throw Configuration DPDT
Electrical Life 25,000 Cycles
Illumination Type, Color LED, Red
Illumination Voltage (Nominal) 5VDC
Panel Cutout Dimensions Square - 19.05mm2
Switch Function On-On
Circuit DPDT
Actuator Type Square, Button (Not Included)
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 2A
Orientation Straight
Current Rating (Amps) 3A AC 2A DC
Voltage - Rated DC 24V
Type Standard, Illuminated
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Full Guard Bezel
Series AML22
Published 1998
Packaging Bulk
Physical
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in, Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 18 Weeks
