AML22HBF2BA
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches SQ 1 H-Profile LED RED 24V SPDT
PDF
/
Inventory: 7318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Gold
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Technical
Packaging Bulk
Published 1998
Series AML22
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard, Illuminated
Voltage - Rated DC 125V
Current Rating (Amps) 100mA AC/DC
Orientation Straight
Current Rating 100mA
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Square, Button (Not Included)
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Square - 19.05mm2
Illumination Voltage (Nominal) 24VDC
Illumination Type, Color LED, Red
Electrical Life 100,000 Cycles
Throw Configuration SPDT
Mechanical Life 100,000 Cycles
Illumination Type LED
Illumination Color Red
Compliance
RoHS Status RoHS Compliant
