AML22HBC2AC
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Switch Push Button N.O./N.C. DPDT Square Button Momentary Contact Quick Connect/Solder Panel Mount
PDF
/
Inventory: 5761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Technical
Packaging Bulk
Published 1998
Series AML22
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard, Illuminated
Voltage - Rated DC 24V
Current Rating (Amps) 3A AC 2A DC
Orientation Straight
Current Rating 2A
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Square, Button (Not Included)
Circuit DPDT
Switch Function On-Mom
Panel Cutout Dimensions Square - 19.05mm2
Illumination Voltage (Nominal) 5VDC
Illumination Type, Color LED, Red
Electrical Life 25,000 Cycles
Throw Configuration DPDT
Mechanical Life 25,000 Cycles
Illumination Type LED
Illumination Color Red
Compliance
RoHS Status RoHS Compliant
