AML22CBX2DD
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches Unsealed OI ADVANCE MAN LINE PB
PDF
/
Inventory: 5939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Illumination Color Green
Illumination Type LED
Mechanical Life 25,000 Cycles
Throw Configuration 4PDT
Electrical Life 25,000 Cycles
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 24VDC
Panel Cutout Dimensions Square - 19.05mm2
Switch Function On-On
Circuit 4PDT
Actuator Type Square, Button (Not Included)
Voltage - Rated AC 125V
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Current Rating 100mA
Orientation Straight
Current Rating (Amps) 100mA AC/DC
Voltage - Rated DC 125V
Type Standard, Illuminated
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series AML22
Published 1998
Packaging Bulk
Physical
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Gold
Supply Chain
Factory Lead Time 18 Weeks
