AML22CBF2BB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches Unsld OI/ADVMAN LINE
PDF
/
Buying Options
Total Price: USD $52.45
Unit Price: USD $52.445103
≥1 USD $52.445103
≥200 USD $20.296121
≥500 USD $19.583216
≥1000 USD $19.230046
Inventory: 2585
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Physical
Contact Material Gold
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Technical
Packaging Bulk
Published 1998
Series AML22
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard, Illuminated
Voltage - Rated DC 125V
Current Rating (Amps) 100mA AC/DC
Orientation Straight
Current Rating 100mA
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Square, Button (Not Included)
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Square - 19.05mm2
Illumination Voltage (Nominal) 24VDC
Illumination Type, Color LED, Red
Electrical Life 25,000 Cycles
Throw Configuration SPDT
Mechanical Life 25,000 Cycles
Illumination Type LED
Illumination Color Red
Compliance
RoHS Status RoHS Compliant
