IHSH36F3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches - Hall Effect
Description
SWITCH PUSH HALL EFFECT 50MA 28V
PDF
/
Inventory: 7056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Front, Panel
Mounting Type Panel Mount, Front
Housing Material PBT
Actuator Material POLYAMIDE
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series IH
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Voltage - Rated DC 28V
Ingress Protection IP67 - Dust Tight, Waterproof
Supply Voltage 3.5V~24VDC
Current Rating 50mA
Termination Style Wire Leads
Voltage - Rated AC 28V
Actuator Type Round Button
Max Output Current 50mA
Circuit Single
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Contact Voltage(DC)-Max 24V
Throw Configuration SPST
Max Output Voltage 28V
Switch Type PUSHBUTTON SWITCH
Operating Force 612gf
Illumination Type Illuminated
Contact (DC) Max Rating R Load 0.05A@24VDC
Actuator Color Green
Actuator Travel 1.778 mm
Body Color Black
Travel Range 1.7mm
Supply Current Varies by Supply Voltage
Dimensions
Actuator Length 0.381 inch
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
