46-260 RED
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH DPDT 0.25A 115V
PDF
/
Buying Options
Total Price: USD $70.17
Unit Price: USD $70.1712
≥1 USD $70.1712
Inventory: 31
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Panel Mount, Rear
Surface Mount NO
Mounting Feature PANEL MOUNT-THREADED
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2010
Series 46
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Standard
Terminal Finish Tin/Silver (Sn/Ag)
HTS Code 8536.50.70.00
Current Rating (Amps) 250mA AC
Ingress Protection Environment Sealed
Termination Style Wire Leads
Voltage - Rated AC 115V
Body Length or Diameter 20.62mm
Actuator Type Round, Button
Circuit DPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 9.92mm Dia
Color - Actuator/Cap Red
Sealing ENVIRONMENTALLY SEALED
Electrical Life 250,000 Cycles
Contact Current(AC)-Max 0.25A
Contact Voltage(AC)-Max 115V
Operating Force-Max 12.51 N
Dimensions
Body Height 29mm
Compliance
RoHS Status RoHS Compliant
