46-05-07-502-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button N.O./N.C. SPDT Plunger 0.25A 220VAC Alternate Contact Panel Mount
PDF
/
Inventory: 9999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Contact (AC) Max Rating R Load .25A@115VAC
Contact Current(AC)-Max 0.25A
Electrical Life 250,000 Cycles
Max Current Rating 250mA
Max Voltage Rating (AC) 220V
Sealing EPOXY TERMINAL SEALED
Color - Actuator/Cap Yellow
Panel Cutout Dimensions Rectangular - 13.10mm x 11.17mm
Switch Function On-On
Circuit SPDT
Actuator Type Round, Button
Body Breadth 14.99 mm
Body Length or Diameter 15.88mm
Voltage - Rated AC 115V
Termination Style Solder Lug
Current Rating 250mA
Current Rating (Amps) 250mA AC
HTS Code 8536.50.70.00
Terminal Finish Tin/Silver (Sn/Ag)
Type Standard
ECCN Code EAR99
Termination Turret
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Series 46
Published 2007
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Housing Material Phenolic
Mounting Type Panel Mount, Front
Mount Front, Panel, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
