38GWSP9V2RT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button OFF (ON) SPST Round Plunger 20VAC 20VDC 0.4VA Momentary Contact PC Pins Thru-Hole
PDF
/
Inventory: 8524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Actuator Type Round, Plunger
Circuit SPST-NO
Switch Function Off-Mom
Color - Actuator/Cap Black
Contact Current(DC)-Max 0.02A
Sealing EPOXY TERMINAL SEALED; IP67
Max Voltage Rating (AC) 20V
Electrical Life 30,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 20V
Contact Current(AC)-Max 0.02A
Contact (AC) Max Rating R Load .02A@20VAC
Contact (DC) Max Rating R Load .02A@20VDC
Body Breadth 5.1 mm
Body Length or Diameter 10.16mm
Voltage - Rated AC 20V
Termination Style PC Pin
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
HTS Code 8536.50.90.31
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type Standard
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Sealed - Fully
JESD-609 Code e4
Series 38G
Published 2007
Packaging Bulk
Operating Temperature -30°C~85°C
Dimensions
Body Height 9.3mm
Compliance
RoHS Status RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
