38FSP9B7M7QT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON SPST 1A 125V
PDF
/
Inventory: 2224
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Body Height 8.13mm
Technical
Contact (DC) Max Rating R Load 1A@28VDC
Contact (AC) Max Rating R Load 1A@125VAC
Contact Current(AC)-Max 1A
Mechanical Life 30000 cycles
Max Voltage Rating (DC) 28V
Throw Configuration SPST
Electrical Life 30,000 Cycles
Max Voltage Rating (AC) 125V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 1A
Color - Actuator/Cap Black
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round, Plunger
Body Breadth 5.08 mm
Body Length or Diameter 9.04mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 1A
Current Rating (Amps) 1A AC/DC
Voltage - Rated DC 28V
HTS Code 8536.50.90.31
Type Standard
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series 38F
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Mounting Type Through Hole, Right Angle, Vertical
Mount Through Hole, Vertical
Contact Plating Silver
Supply Chain
Factory Lead Time 18 Weeks
