30-37-EW
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button N.O. SPST Round Button 1A 220VAC Momentary Contact Solder Lug Panel Mount
PDF
/
Inventory: 9798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Panel
Mounting Type Panel Mount, Rear
Housing Material Plastic
Actuator Material Polycarbonate
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2010
Series 30
Feature Epoxy Potted, Overtravel
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard
HTS Code 8536.50.70.00
Current Rating (Amps) 1A AC
Orientation Straight
Depth 9.53mm
Current Rating 1A
Termination Style Wire Leads
Voltage - Rated AC 115V
Actuator Type Round, Plunger
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 6.75mm Dia
Contact Resistance 25mOhm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 220V
Max Current Rating 1A
Electrical Life 500,000 Cycles
Throw Configuration SPST
Dimensions
Length 9.53mm
Actuator Length 3.81mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
