51-256.025
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
EAO 51-256.025 Industrial Pushbutton Switch, 1NO / 1NC, Off-On, Solder, 5 A, 250 V, 250 V
PDF
/
Buying Options
Total Price: USD $37.9
Unit Price: USD $37.9016
≥1 USD $37.9016
≥10 USD $33.84656
≥100 USD $31.64304
≥500 USD $28.910816
≥1000 USD $27.059648
≥3000 USD $25.296832
Inventory: 455
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Gold
Mount Panel
Mounting Type Panel Mount, Front
Body Material Plastic
Technical
Operating Temperature -25°C~55°C
Packaging Bulk
Series 51
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Type Emergency Stop
Number of Positions 2
Current Rating (Amps) 5A AC
Ingress Protection IP65 - Dust Tight, Water Resistant
Depth 18mm
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 250V
Actuator Type Round, Button
Circuit DPST-NO/NC
Switch Function On-Off, Off-On
Panel Cutout Dimensions Circular - 16.00mm Dia
Color - Actuator/Cap Red
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Throw Configuration 4PST, DPST
Mechanical Life 1,000,000 Cycles
Contact Current Rating 5A
Index Angle 90 °
Dimensions
Length 18mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings IP65
