19-431.035
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Switches / Pushbutton Switches
Description
EAO 19-431.035 Industrial Pushbutton Switch, 19 Series, SPST-NO, Off-(On), Solder, 100 mA, 50 V
PDF
/
Buying Options
Total Price: USD $17.08
Unit Price: USD $17.0808
≥1 USD $17.0808
≥10 USD $15.51352
≥100 USD $13.509144
Inventory: 117
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Gold
Mount Panel
Mounting Type Panel Mount, Front
Package / Case 100
Technical
Operating Temperature -25°C~65°C
Packaging Bulk
Series 19
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Type Standard
Current Rating (Amps) 100mA AC
Ingress Protection IP40
Termination Style Solder, Quick Connect - 0.079 (2.0mm)
Voltage - Rated AC 50V
Actuator Type Round, Button (Not Included)
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 8.00mm Dia
Contact Resistance 15mOhm
Throw Configuration SPST
Mechanical Life 2,000,000 Cycles
Contact Current Rating 100mA
Dimensions
Width 9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
