PBH2UOASAGX
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH DPDT 0.1A 30V
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.163229
≥1 USD $1.163229
≥200 USD $0.450325
≥500 USD $0.43457
≥1000 USD $0.426693
Inventory: 3908
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Insulation Material POLYAMIDE
Housing Material POLYBUTYLENE TEREPHTHALATE
Actuator Material POLYOXYMETHYLENE
Center Contact Plating SILVER
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
End Contact Plating SILVER
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2006
Series PBH
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Standard
Voltage - Rated DC 30V
Current Rating (Amps) 100mA DC
Current Rating 100mA
Termination Style PC Pin
Body Length or Diameter 7.2898mm
Body Breadth 9.0932 mm
Actuator Type Plunger for Cap
Circuit DPDT
Switch Function On-Mom
Contact Resistance 0.1mOhm
Insulation Resistance 100000000Ohm
Color - Actuator/Cap White
Contact Current(DC)-Max 0.1A
Dielectric Withstanding Voltage 250VAC V
Electrical Life 10,000 Cycles
Mechanical Life 30,000 Cycles
Contact Timing MAKE-BEFORE-BREAK
Contact (DC) Max Rating R Load 0.1A@30VDC
PCB Hole Count 6
Actuator Travel 2.9972 mm
Dimensions
Body Height 14.7066mm
Length - Termination 0.157 inch
Actuator Length 0.413 inch
Compliance
RoHS Status ROHS3 Compliant
