PA5F11C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON SPST 16A 125V
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.199991
≥1 USD $1.199991
≥200 USD $0.464767
≥500 USD $0.447699
≥1000 USD $0.439822
Inventory: 3410
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Panel Mount, Rear
Surface Mount NO
Actuator Material POLYBUTYLENE TEREPHTHALATE
Center Contact Material SILVER ALLOY
Terminal Material COPPER
End Contact Material SILVER ALLOY
Technical
Operating Temperature -20°C~125°C
Packaging Bulk
Published 2011
Series PA5, LAMB
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Standard
Current Rating (Amps) 16A AC
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Body Length or Diameter 18.796mm
Body Breadth 12.8016 mm
Actuator Type Square, Plunger
Circuit SPST
Switch Function Off-On
Contact Resistance 0.02mOhm
Insulation Resistance 100000000Ohm
Dielectric Withstanding Voltage 1000V V
Electrical Life 10,000 Cycles
Contact Current(AC)-Max 16A
Contact (AC) Max Rating R Load 16A@250VAC
Contact Voltage(AC)-Max 250V
Actuator Travel 5.0038 mm
Dimensions
Body Height 14.5034mm
Length - Termination 0.335 inch
Actuator Length 0.374 inch
Compliance
RoHS Status ROHS3 Compliant
