LP6OA1ASWW
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPST-NO 12MA 12V
PDF
/
Buying Options
Total Price: USD $10.71
Unit Price: USD $10.705428
≥1 USD $10.705428
≥10 USD $10.09946
≥100 USD $9.527787
≥500 USD $8.988488
≥1000 USD $8.479703
Inventory: 3984
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.335 inch
Length - Termination 0.138 inch
Body Height 12.192mm
Technical
Actuator Travel 2.2098 mm
PCB Hole Count 9
Contact (DC) Max Rating R Load 0.012A@12VDC
Illumination Type LED
Mechanical Life 200,000 Cycles
Throw Configuration SPST
Electrical Life 200,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Illumination Type, Color LED, White/White
Illumination Voltage (Nominal) 3.5VDC
Contact Current(DC)-Max 0.012A
Color - Actuator/Cap Clear
Insulation Resistance 100000000Ohm
Contact Resistance 0.05mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Square, Button
Body Breadth 15.494 mm
Body Length or Diameter 15.494mm
Termination Style PC Pin
Current Rating 12mA
Current Rating (Amps) 12mA DC
Voltage - Rated DC 12V
Type Standard, Illuminated
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LP6
Published 2013
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Plating GOLD
Center Contact Plating GOLD
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
