LAKOAU110BLU
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON SPDT 8A 125V
PDF
/
Inventory: 8714
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Front, Panel
Mounting Type Panel Mount, Front
Center Contact Plating SILVER
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
End Contact Plating SILVER
Technical
Operating Temperature -20°C~55°C
Packaging Bulk
Published 2008
Series LA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Type Standard
Voltage - Rated DC 24V
Current Rating (Amps) 8A AC 6A DC
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 6A
Termination Style Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Round, Button, Flush
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 22.00mm Dia
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Blue
Contact Current(DC)-Max 0.2A
Contact Voltage(DC)-Max 250V
Electrical Life 50,000 Cycles
Mechanical Life 100,000 Cycles
Contact Current(AC)-Max 5A
Contact (AC) Max Rating R Load 5A@250VAC
Contact (DC) Max Rating R Load 0.2A@250VDC
Contact Voltage(AC)-Max 250V
Dimensions
Length - Termination 0.315 inch
Actuator Length 0.551 inch
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP65, Water Resistant
