D16OAS11JGRNGRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches Pushbutton Switch SPDT 8A 125V
PDF
/
Inventory: 5236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Silver
Mount Front, Panel
Mounting Type Panel Mount, Front
Housing Material Polyetherimide
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
Technical
Operating Temperature -20°C~55°C
Packaging Bulk
Series D16
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard, Illuminated
Voltage - Rated DC 24V
Current Rating (Amps) 8A AC 6A DC
Current Rating 6A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Square, Button
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 16.00mm Dia
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Color - Actuator/Cap Green
Contact Current(DC)-Max 6A
Illumination Voltage (Nominal) 12VDC
Illumination Type, Color LED, Green
Electrical Life 50,000 Cycles
Mechanical Life 100,000 Cycles
Illumination Type LED
Contact Current(AC)-Max 5A
Contact (AC) Max Rating R Load 5A@250VAC
Hole Diameter 16 mm
Contact Voltage(AC)-Max 250V
Dimensions
Actuator Length 0.425 inch
Compliance
RoHS Status ROHS3 Compliant
