D16EET22CRED
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches Pushbutton Switch DPDT 8A 125V
PDF
/
Inventory: 2283
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Hole Diameter 16 mm
Illumination Type Illuminated
Mechanical Life 100,000 Cycles
Electrical Life 50,000 Cycles
Illumination Type, Color Incandescent, Red
Illumination Voltage (Nominal) 28VAC/DC
Color - Actuator/Cap Red
Panel Cutout Dimensions Circular - 16.00mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Rectangular, Button, Flush
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 6A
Current Rating (Amps) 8A AC 6A DC
Voltage - Rated DC 24V
Type Standard, Illuminated
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series D16
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Housing Material Polyetherimide
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Silver
