D16EET12HYELYEL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches DPST ILLUM YEL
PDF
/
Inventory: 4085
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.402 inch
Length - Termination 0.13 inch
Technical
Actuator Travel 2.9972 mm
Contact Voltage(AC)-Max 250V
Hole Diameter 16 mm
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Illumination Type LED
Contact Current Rating 8A
Mechanical Life 100,000 Cycles
Throw Configuration DPDT, DPST
Electrical Life 50,000 Cycles
Illumination Type, Color LED, Yellow
Illumination Voltage (Nominal) 6VDC
Color - Actuator/Cap Yellow
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Panel Cutout Dimensions Circular - 16.00mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Rectangular, Button
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 6A
Current Rating (Amps) 8A AC 6A DC
Voltage - Rated DC 24V
Type Standard, Illuminated
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series D16
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material Polyetherimide
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Silver
Supply Chain
Factory Lead Time 9 Weeks
