D16EES12FGRNWHT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches Pushbutton Switch DPDT 8A 125V
PDF
/
Inventory: 7400
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.409 inch
Technical
Actuator Travel 2.9972 mm
Contact Voltage(AC)-Max 250V
Hole Diameter 16 mm
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Illumination Type Illuminated, Neon
Mechanical Life 100,000 Cycles
Electrical Life 50,000 Cycles
Illumination Type, Color Neon, Green
Illumination Voltage (Nominal) 110VAC
Contact Current(DC)-Max 6A
Color - Actuator/Cap White
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Panel Cutout Dimensions Circular - 16.00mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Square, Button
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 6A
Current Rating (Amps) 8A AC 6A DC
Voltage - Rated DC 24V
Additional Feature 110VAC, GREEN COLOR BULB
Type Standard, Illuminated
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series D16
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material Polyetherimide
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Silver
