800SP8B10M1RE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.101523
≥1 USD $1.101523
Inventory: 7487
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.146 inch
Length - Termination 0.11 inch
Body Height 8.636mm
Technical
Contact Function ON-(ON)
Mechanical Life 50,000 Cycles
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Sealing EPOXY
Color - Actuator/Cap Black
Insulation Resistance 1000000000Ohm
Contact Resistance 0.02mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-Mom
Circuit SPDT
Actuator Type Round, Plunger
Body Breadth 5.08 mm
Body Length or Diameter 8.128mm
Voltage - Rated AC 20V
Termination Style Solder Lug
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Type Standard
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 800
Published 2006
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Housing Material STAINLESS STEEL
Insulation Material DIALLYL PHTHALATE
Mounting Type Panel Mount, Rear
Mount Panel
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
