TP11LTZGE

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description Pushbutton Switches Pushbutton
PDF
/
Inventory: 9483
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Silver
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount, Rear
Housing Material Stainless Steel
Actuator Material Polyester, Thermoplastic

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Published 2011
Series TP
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 1A AC/DC
Orientation Straight
Depth 7.11mm
Current Rating 1A
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Round, Plunger
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Color - Actuator/Cap Black
Max Voltage Rating (AC) 120V
Max Current Rating 1A
Electrical Life 60,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 28V

Dimensions

Length 8.13mm
Actuator Length 5.46mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
