E225SD1CBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH DPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $8.24
Unit Price: USD $8.2368
≥1 USD $8.2368
≥10 USD $7.4448
≥100 USD $7.086464
≥500 USD $7.0092
Inventory: 66
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 7.16mm
Length 12.7mm
Technical
Illumination Type Illuminated
Max Voltage Rating (DC) 20V
Electrical Life 60,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap White
Switch Function On-Mom
Circuit DPDT
Actuator Type Round, Plunger
Voltage - Rated AC 20V
Termination Style PC Pin
Depth 11.43mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Type Standard
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Process Sealed
Series E020
Published 2012
Packaging Tray
Operating Temperature -30°C~75°C
Physical
Actuator Material Glass, Nylon, Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
