8121J81CGE23
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Switch Push Button ON Mom SPDT Button 1A 120VAC 28VDC 0.4VA Momentary Contact PC Pins Panel Mount/Through Hole
PDF
/
Inventory: 4501
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Panel, Snap in, Through Hole
Mounting Type Panel Mount, Snap-In
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~75°C
Packaging Bulk
Published 2012
Series 8020
Feature Tactile Feedback
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Type Standard
Max Operating Temperature 75°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 1A AC/DC
Orientation Straight
Depth 15.62mm
Current Rating 1A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Square, Button
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Rectangular - 15.24mm x 12.70mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 120V
Max Current Rating 1A
Electrical Life 60,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 28V
Dimensions
Length 19.43mm
Actuator Length 1.57mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
