MP0033
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
BULGIN MP0033 SWITCH, INDUSTRIAL PUSHBUTTON, 22MM
PDF
/
Buying Options
Total Price: USD $23.62
Unit Price: USD $23.6192
≥1 USD $23.6192
≥10 USD $21.45264
≥100 USD $20.488512
≥500 USD $19.404
≥1000 USD $18.680816
≥3000 USD $17.475603
Inventory: 124
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Sealed, IP54
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 800μm
Length 22.1mm
Diameter 22.1mm
Technical
Contact Timing MAKE-BEFORE-BREAK
Contact Current(AC)-Max 1A
Illumination Type Illuminated
Contact Current Rating 1A
Throw Configuration SP, SPST
Number of Poles 1
Dielectric Withstanding Voltage 2500VAC V
Max Current Rating 1A
Max Voltage Rating (AC) 50V
Sealing ENVIRONMENTALLY SEALED
Color - Actuator/Cap Silver
Contact Resistance 15mOhm
Panel Cutout Dimensions Circular - 19.20mm Dia
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round, Button, Flush
Voltage - Rated AC 50V
Termination Style Screw Terminal
Current Rating 1A
Depth 22.1mm
Ingress Protection Environment Sealed
Orientation Straight
Current Rating (Amps) 1A AC
Voltage - Rated DC 50V
HTS Code 8536.50.70.00
Type Standard
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2005
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Actuator Material Stainless Steel
Housing Material Brass
Mounting Type Panel Mount, Front
Mount Front, Panel, Screw
Contact Material Copper
Supply Chain
Factory Lead Time 24 Weeks
