TP32WS83500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $5.74
Unit Price: USD $5.73606
≥1 USD $5.73606
≥200 USD $2.220114
≥700 USD $2.142653
≥1400 USD $2.103266
Inventory: 1195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Brass, Gold
Mount PCB, Surface Mount
Mounting Type Surface Mount, Right Angle
Housing Material Plastic
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SMT TP
JESD-609 Code e0
Feature Washable in solvent or degreaser
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Type Standard
Terminal Finish Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Additional Feature TAPE AND REEL PACKAGING
HTS Code 8536.50.90.65
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Packing Method TAPE AND REEL
Termination Style Gull Wing
Voltage - Rated AC 20V
Body Length or Diameter 10.16mm
Body Breadth 8.1 mm
Actuator Type Round, Plunger
Circuit SPDT
Switch Function On-Mom
Contact Resistance 0.05mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.02A
Sealing MOISTURE PROOF; SHOCK PROOF
Electrical Life 60,000 Cycles
Contact Current Rating 400mA
Contact Current(AC)-Max 0.02A
Contact (AC) Max Rating R Load .02A@20VAC
Contact (DC) Max Rating R Load .02A@20VDC
PCB Hole Count 5
Contact Function ON-(ON)
Actuator Travel 0.9906 mm
Solderability REFLOW
Bushing Length 0.202 inch
Dimensions
Body Height 5.55mm
Actuator Length 0.177 inch
Compliance
RoHS Status ROHS3 Compliant
