PBAR6AF3000

APEM Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description SWITCH PUSH SPST-NO 0.2A 24V
PDF
/
Inventory: 2352
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Front, Panel
Mounting Type Panel Mount, Front

Technical

Operating Temperature -40°C~75°C
Packaging Bulk
Series PBA
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Type Piezo
HTS Code 8536.50.90.33
Voltage - Rated DC 24V
Current Rating (Amps) 200mA AC/DC
Ingress Protection IP68 - Dust Tight, Waterproof
Current Rating 200mA
Termination Style Wire Leads
Voltage - Rated AC 24V
Body Length or Diameter 22mm
Actuator Type Round, Button, Flush
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 22.20mm Dia
Color - Actuator/Cap Green
Contact Current(DC)-Max 1A
Electrical Life 50,000,000 Cycles
Throw Configuration SPST
Contact (DC) Max Rating R Load 1A@24VDC

Dimensions

Body Height 19.5mm

Compliance

RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP68, Waterproof
