LPI5106R1K51711
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON DPST 5A 12V
PDF
/
Buying Options
Total Price: USD $65.44
Unit Price: USD $65.436249
≥1 USD $65.436249
≥195 USD $25.323215
≥495 USD $24.433069
≥1005 USD $23.993248
Inventory: 4936
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP53, Water Resistant
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 0.256 inch
Body Height 19.812mm
Technical
Actuator Travel 2.0066 mm
Contact (DC) Max Rating R Load 5A@12VDC
Illumination Color Red
Illumination Type LED
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 12V
Throw Configuration DPST, SPST
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Illumination Type, Color LED, Red
Illumination Voltage (Nominal) 6VDC
Contact Current(DC)-Max 5A
Color - Actuator/Cap White
Insulation Resistance 10000000Ohm
Contact Resistance 100mOhm
Panel Cutout Dimensions Circular - 38.10mm Dia
Switch Function On-Mom, Off-Mom
Circuit DPST-NO/NC
Actuator Type Round, Button, Flush
Body Length or Diameter 43.9928mm
Termination Style Screw Terminal
Current Rating 5A
Ingress Protection IP53 - Dust Protected, Water Resistant
Orientation Straight
Current Rating (Amps) 5A DC
Voltage - Rated DC 12V
Type Standard, Illuminated
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
Series LPI
Packaging Tray
Operating Temperature -20°C~65°C
Physical
Package / Case SMD/SMT
Mounting Type Panel Mount, Front
Mount Front, Panel, Surface Mount
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 9 Weeks
