AV22PNA6B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON DPDT 6A 250V
PDF
/
Buying Options
Total Price: USD $53.31
Unit Price: USD $53.306366
≥1 USD $53.306366
Inventory: 8573
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Body Height 21.4mm
Technical
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Contact Current Rating 5A
Mechanical Life 1,000,000 Cycles
Electrical Life 100,000 Cycles
Sealing IP65
Color - Actuator/Cap Red
Panel Cutout Dimensions Circular - 22.20mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Round, Button, Mushroom
Body Length or Diameter 30mm
Voltage - Rated AC 250V
Termination Style Quick Connect - 0.110 (2.8mm)
Current Rating 6A
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating (Amps) 6A AC
HTS Code 8536.50.70.00
Type Anti-Vandal
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Fully
Series AV
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Housing Material Polyester
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Nickel
Supply Chain
Factory Lead Time 11 Weeks
