AV22LP402
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Switches / Pushbutton Switches
Description
PUSHBUTTON, METAL, FLAT, 22MM 5A
PDF
/
Buying Options
Total Price: USD $176.98
Unit Price: USD $176.983683
≥1 USD $176.983683
≥10 USD $166.965736
≥100 USD $157.514845
≥500 USD $148.598917
≥1000 USD $140.187655
Inventory: 2134
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP65, IP67, Waterproof
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 0m
Technical
Operating Force-Max 14 N
Contact (AC) Max Rating R Load 5A@250VAC
Contact Current(AC)-Max 5A
Contact Current Rating 5A
Mechanical Life 3,000,000 Cycles
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 250V
Insulation Resistance 1GOhm
Contact Resistance 100mOhm
Panel Cutout Dimensions Circular - 22.20mm Dia
Switch Function On-Mom
Circuit SPDT
Actuator Type Round, Button, Flush
Body Length or Diameter 26mm
Voltage - Rated AC 250V
Termination Style Solder Lug
Current Rating 5A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 5A AC
HTS Code 8536.50.70.00
Type Anti-Vandal
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Fully
Series AV
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Actuator Material Stainless Steel
Housing Material Polyester
Package / Case Metal
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Silver
Supply Chain
Factory Lead Time 11 Weeks
