AV09C7L3D2001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Tamper-proof pushbutton 24 Vac 0.05 A 1 x On/(On) APEM
PDF
/
Inventory: 7299
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Brass, Gold
Mount Front, Panel
Mounting Type Panel Mount, Front
Material Metal
Technical
Operating Temperature -30°C~70°C
Packaging Bulk
Series AV
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Anti-Vandal, Illuminated
HTS Code 8536.50.90.31
Voltage - Rated DC 24V
Current Rating (Amps) 50mA DC
Ingress Protection IP54 - Dust Protected, Water Resistant
Current Rating 50mA
Termination Style Solder Lug
Body Length or Diameter 22mm
Actuator Type Round, Button, Flush
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 19.20mm Dia
Color - Actuator/Cap Silver
Contact Current(DC)-Max 0.05A
Illumination Voltage (Nominal) 2VDC
Illumination Type, Color LED, Blue
Electrical Life 1,000,000 Cycles
Throw Configuration SPST
Mechanical Life 100,000 Cycles
Illumination Type LED
Contact (DC) Max Rating R Load .05A@24VDC
Operating Force-Max 9 N
Dimensions
Body Height 26.7mm
Compliance
RoHS Status ROHS3 Compliant
Ratings IP54, Water Resistant
