9533NCD4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPST-NO 0.1A 30V
PDF
/
Inventory: 3349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Panel
Mounting Type Panel Mount, Rear
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Series 9000
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard
HTS Code 8536.50.90.31
Voltage - Rated DC 30V
Current Rating (Amps) 100mA DC
Current Rating 100mA
Termination Style Solder Lug
Body Length or Diameter 6.5mm
Actuator Type Round, Plunger
Circuit SPST-NO
Switch Function Off-Mom
Panel Cutout Dimensions Circular - 4.20mm Dia
Color - Actuator/Cap Black
Contact Current(DC)-Max 0.1A
Sealing EPOXY TERMINAL SEALED
Electrical Life 250,000 Cycles
Throw Configuration SPST
Contact (DC) Max Rating R Load .1A@30VDC
Dimensions
Body Height 6.1mm
Compliance
RoHS Status ROHS3 Compliant
