810K2MZB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.646377
≥1 USD $1.646377
Inventory: 4911
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Bushing, Panel
Mounting Type Panel Mount, Rear
Housing Material Resin
Actuator Material Glass, Polyamide
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Series 800
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Termination Style Solder Lug
Voltage - Rated AC 20V
Body Length or Diameter 12.7mm
Body Breadth 7.366 mm
Actuator Type Plunger for Cap
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Contact Resistance 20mOhm
Insulation Resistance 2000000000Ohm
Color - Actuator/Cap White
Sealing EPOXY
Max Voltage Rating (AC) 20V
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 60,000 Cycles
Throw Configuration SP, SPDT
Max Voltage Rating (DC) 20V
Contact Function ON-(ON)
Bushing Length 0.25 inch
Dimensions
Body Height 10.668mm
Length - Termination 0.172 inch
Actuator Length 5.85mm
Compliance
RoHS Status ROHS3 Compliant
