760301303
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Transformers / Pulse Transformers
Description
XFRMR GATE DRIVE SMD
PDF
/
Buying Options
Total Price: USD $6.9
Unit Price: USD $6.8992
≥1 USD $6.8992
≥10 USD $6.38792
Inventory: 985
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-GDT
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Inductance 750μH
DC Resistance (DCR) 1.1Ohm
Isolation Voltage 2.5kV
Transformer Type Gate Drive
Turns Ratio - Primary:Secondary 2.1:1
ET (Volt-Time) 102VμS
Dimensions
Height 11mm
Height Seated (Max) 0.433 11.00mm
Length 10.5mm
Width 10.5mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
