ITRB-0249-D101 image
Favorite
ITRB-0249-D101 image
Favorite

ITRB-0249-D101

Schurter Inc.
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Pulse Transformers
Description ITRB PULSE TRANSFORMER THT 0.1A
PDF
/
Inventory: 3299
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 17.8mm
Length 18.2mm
Height Seated (Max) 0.512 13.00mm

Technical

Pulse Rise Time-Max 50ns
ET Product-Min 250 V-us
ET (Volt-Time) 250VμS
Turns Ratio - Primary:Secondary 2:01
Transformer Type SCR and Triac Trigger (Encapsulated)
Isolation Voltage 3200V
Application GENERAL PURPOSE
DC Resistance (DCR) 1Ohm
Inductance 1.4mH
Physical Dimension L18.2XB17.8XH13.0 (mm)
Approval Agency VDE
Number of Functions 1
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
JESD-609 Code e3
Size / Dimension 0.701Lx0.717W 17.80mmx18.20mm
Series IT
Published 2014
Packaging Bulk
Operating Temperature -25°C~100°C

Physical

Weight 0.32oz 9.12g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 23 Weeks
