IT260
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
XFRMR PULSE 3:1 SGL 12MH .1A
PDF
/
Buying Options
Total Price: USD $10.03
Unit Price: USD $10.032
≥1 USD $10.032
≥10 USD $7.4096
≥100 USD $6.83936
≥500 USD $6.61144
≥1000 USD $6.428972
≥3000 USD $6.33776
Inventory: 481
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 16.7mm
Height Seated (Max) 0.445 11.30mm
Height 11.3mm
Technical
Pulse Rise Time-Max 300ns
ET Product-Min 200 V-us
Turns Ratio (NpNs) 3:1
Turns Ratio - Primary:Secondary 3:1
Transformer Type Data/Voice Coupling
Isolation Voltage 500V
Application GENERAL PURPOSE
Lead/Base Style PC Pin
DC Resistance (DCR) 2Ohm
Inductance 12mH
Physical Dimension L17.6XB16.7XH11.3 (mm)
Approval Agency UL
Frequency 40kHz
Depth 17.6mm
Number of Functions 1
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 0.693Lx0.657W 17.60mmx16.70mm
Series IT
Published 2008
Packaging Tray
Operating Temperature -25°C~70°C
Physical
Weight 0.2oz 5.7g
Number of Pins 4
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
