IT255
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
SCHAFFNER IT255TRANSFORMER, PULSE, 1:1, 2.2mH
PDF
/
Buying Options
Total Price: USD $6.51
Unit Price: USD $6.512
≥1 USD $6.512
≥10 USD $4.94824
≥100 USD $4.817824
≥500 USD $4.42706
≥1000 USD $4.166712
≥3000 USD $4.036498
Inventory: 2162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 16.7mm
Height Seated (Max) 0.445 11.30mm
Height 11.3mm
Technical
ET Product-Min 250 V-us
Turns Ratio (NpNs) 1:1
Turns Ratio - Primary:Secondary 1:1
Transformer Type Data/Voice Coupling
Isolation Voltage 4kV
Rise Time 1.1μs
Application GENERAL PURPOSE
Lead/Base Style PC Pin
DC Resistance (DCR) 800mOhm
Inductance 2.2mH
Physical Dimension L17.6XB16.7XH11.3 (mm)
Approval Agency UL
Frequency 40kHz
Depth 17.6mm
Number of Functions 1
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 0.693Lx0.657W 17.60mmx16.70mm
Series IT
Published 2008
Packaging Tray
Operating Temperature -25°C~70°C
Physical
Weight 0.2oz 5.7g
Number of Pins 4
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
