X-1569
RoHS
/
Package SMD/SMT
Category Transformers / Pulse Transformers
Description
XFMR GATE DRIVE 1500VDC ISO
PDF
/
Buying Options
Total Price: USD $9.81
Unit Price: USD $9.812
≥1 USD $9.812
≥10 USD $7.25032
≥100 USD $6.692576
≥500 USD $6.469584
≥1000 USD $6.29112
≥3000 USD $6.201853
Inventory: 203
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 9.01mm
Height Seated (Max) 0.300 7.62mm
Technical
ET (Volt-Time) 45.1VμS
Turns Ratio - Primary:Secondary 1:1.1
Transformer Type Gate Drive
DC Resistance (DCR) 1.6Ohm
Inductance 3.3mH
Depth 8.63mm
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.355Lx0.340W 9.01mmx8.63mm
Published 2011
Packaging Bulk
Operating Temperature -40°C~130°C
Physical
Number of Pins 8
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
Alternative Model
