SGQN1553-45
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
Interface MIL-STD-1553 Surface Mount Active Non-RoHS Compliant Pulse Transformer 1Ohm
PDF
/
Buying Options
Total Price: USD $216.23
Unit Price: USD $216.232004
≥1 USD $216.232004
≥200 USD $86.278536
≥500 USD $83.395408
≥1000 USD $81.970912
Inventory: 2569
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.344 8.74mm
Technical
Turns Ratio - Primary:Secondary 1:2.5
Transformer Type Interface, MIL-STD-1553
DC Resistance (DCR) 1Ohm
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.630Lx0.630W 16.00mmx16.00mm
Physical
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
