DGLN1553-45
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
Pulse Transformer 1CT:2.5CT/1CT:1.79CT 100Vrms 1Ohm Prim. DCR 3.5Ohm Sec. DCR 16Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $186.01
Unit Price: USD $186.011672
≥1 USD $186.011672
≥200 USD $74.220863
≥500 USD $71.740795
≥1000 USD $70.514546
Inventory: 7240
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 23.6mm
Height Seated (Max) 0.159 4.04mm
Technical
Turns Ratio - Primary:Secondary 1:2.5
Transformer Type Interface, MIL-STD-1553
Lead/Base Style Gull Wing
DC Resistance (DCR) 1Ohm
Depth 27.68mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.930Lx0.630W 23.62mmx16.00mm
Physical
Number of Pins 16
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
